High Pressure PTFE Seals
Special Seal Design
Size range from 30mm 0/dia to 530 0/dia
Pressure up to 5 bar. Vacuum 0.1 torr
Metal parts = stainless steel (BS 1449 Pt2 1983/ANSI 1316)
Sealing element = black or white PTFE
Captive Elastomer = VITON (up to 250C)
Special Seal Design
Size range from 30mm 0/dia to 530 0/dia
Pressure up to 5 bar. Vacuum 0.1 torr
Metal parts = stainless steel (BS 1449 Pt2 1983/ANSI 1316)
Sealing element = black or white PTFE
Captive Elastomer = VITON (up to 250C)
Special Seal Design
Size range from 46mm 0/dia to 530 0/dia
Pressure up to 5 bar. Vacuum 0.1 torr
Metal parts = stainless steel (BS 1449 Pt2 1983/ANSI 1316)
Sealing element = black or white PTFE
Captive Elastomer = VITON (up to 250C)
P.T.F.E. Element is supported by metal outer case
